Dust Cap Type Dust Cap Color Connector Type Connector Color Boot Type Boot Color Crimping Type
Standard White PC uniboot Brown Standard Blue Standard ψ1.4
  Black APC uniboot Green Short Boot Green Standard ψ1.7
    PC 0.9mm SX   Bendable Boot Black Standard ψ1.8
    PC 0.9mm DX   45° Boot White Standard ψ2.0
    APC 0.9mm SX   90° Boot Gray Standard ψ2.1
    APC 0.9mm DX     Red Standard ψ2.4
    PC 2.0/3.0mm SX     Brown Standard ψ2.8
    PC 2.0/3.0mm DX     Orange Standard ψ3.0
    APC 2.0/3.0mm SX     Pink LC Crimp with White Shrink Tube
    APC 2.0/3.0mm DX     Yellow LC Crimp with Yellow Shrink Tube
          Aqua Teeth Crimp ψ1.7
          Magenga Teeth Crimp ψ1.8
          Beige Teeth Crimp ψ2.0
            Teeth Crimp ψ2.1



Cable Type Cable OD Jacket Color Jacket Material Fiber Type
Simplex 0.6mm Blue PVC SM G652D
Duplex fig 8 0.9mm Green LSZH SM G655
Duplex fig 0 1.4mm Black Hytrel SM G657 A1
Unibootable 1.7mm White   SM G657 A2
4C 1.8mm Gray   SM G657 B
6C 2.0mm Red   MM OM1 62.5/125
8C 2.1mm Brown   MM OM2 50/125
12C 2.4mm Orange   MM OM3 50/125
24C 2.7mm Pink   MM OM4 50/125
48C 2.8mm Yellow   SMF28 Ultra
(0.9mm) Loose Tube 3.0mm Aqua
(0.9mm) Tigthbuffer   Magenta
(0.9mm) Semi-Tigthbuffer
