Dust Cap Type Dust Cap Color Connector Type Connector Color Boot Type Boot Color Crimping Type
Standard Transparent 0.9/2.0/3.0mm SX (Zinc Flange) Metal Standard 0.9mm Blue Standard ψ2.0
DustCap and Chain Blue 0.9/2.0/3.0mm SX (Brass-Ni Flange) Plastic (Black) Soft 0.9mm Green Standard ψ2.8
  Green     Soft 2.0mm Black Standard ψ3.0
  Black     Soft 3.0mm White Teeth Crimp ψ1.7
  White       Gray
  Gray       Red
  Red       Brown
  Brown       Orange
  Orange       Pink
  Pink       Yellow
  Yellow       Aqua
  Aqua       Magenta
  Magenta       Beige



Cable Type Cable OD Jacket Color Jacket Material Fiber Type
Simplex 0.6mm Blue PVC SM G652D
Duplex fig 8 0.9mm Green LSZH SM G655
Duplex fig 0 1.7mm Black Hytrel SM G657 A1
Unibootable 1.8mm White   SM G657 A2
4C 2.0mm Gray   SM G657 B
6C 2.8mm Red   MM OM1 62.5/125
8C 3.0mm Brown   MM OM2 50/125
12C   Orange   MM OM3 50/125
24C   Pink   MM OM4 50/125
48C   Yellow   SMF28 Ultra
(0.9mm) Loose Tube   Aqua
(0.9mm) Tigthbuffer   Magenta
(0.9mm) Semi-Tigthbuffer
